360° Panoramic PTZ Network Dome Camera

The 360° PTZ Panoramic Network Dome Camera combines a panoramic wide-angle view with pan-tilt-zoom (PTZ) functionality, providing comprehensive surveillance coverage with a single device.

It enables operators to swiftly pan, tilt, and zoom to focus on specific details—such as people, vehicles, or abnormal events.

Supporting 4K UHD imaging, 20x optical zoom, and low-light performance, the camera delivers clear visuals even under challenging lighting conditions.

With IP66 weatherproof protection, it is ideal for public spaces, parking lots, shopping mall atriums, and transportation hubs, where wide-area monitoring and real-time event response are essential.

Compared to fixed-lens cameras, the panoramic + PTZ combination offers greater flexibility, coverage, and situational awareness, and can integrate seamlessly with multi-camera management systems or existing VMS platforms for real-time tracking and efficient playback—meeting the professional needs of airspace control and intelligent transportation systems.

Product Specifications Contact Us Now

Panoramic View

360° coverage, no blind spots

Optical Zoom

20× / 30× / 40× high-magnification zoom options

High-Resolution Imaging

2MP / 4MP / 5MP HD video output

Night Vision

Infrared night vision / low-light full-color modes

AI Video Analytics

Intrusion, loitering, boundary crossing, vehicle detection

PTZ Flexible Control

Remote rotation, patrol, and preset position monitoring

Real-Time Event Alerts

Instant push notifications upon anomaly detection

Rugged Design

Industrial-grade IP66 / IK10 protection for outdoor use

System Integration

ONVIF / API support for VMS compatibility

Flexible Installation

Wall, pole, or ceiling mount options

Key Features

Full 360° Panoramic Coverage

Wide-angle lens eliminates blind spots, enabling full-area surveillance with fewer cameras.
PTZ Control & Zoom

Remote pan, tilt, and zoom to quickly focus on incidents or key subjects.
High-Definition Imaging

Equipped with high-resolution sensors (up to 4K) for crisp detail capture in both day and night conditions.

Low-Light & Night Vision

Infrared and low-light color modes ensure reliable imaging in dark or low-illumination environments.
AI Intelligent Detection

Supports behavior analysis, intrusion detection, object left-behind alerts, boundary detection, and vehicle access management.
Remote Control & API Integration

Easily integrates with control centers or management systems for live streaming and event-triggered responses.

Weather-Resistant & Durable

Rated IP66/IP67 for dust and water resistance, with wide temperature tolerance for outdoor or harsh conditions.

Product Specifications

Image Sensor	High-resolution CMOS sensor (2MP / 4MP / 5MP optional)
Lens	Optical zoom 20× / 30× / 40× optional; supports digital zoom
Image Resolution	1920×1080 / 2560×1440 / 2688×1520 / 4K (depending on model)
Video Compression	H.264 / H.265 / MJPEG
Night Vision Capability	Infrared illumination range: 100m–150m; supports low-light full-color mode
PTZ Control	Pan: 360° endless rotation Tilt: 0°–90° Speed: 0.1°–200°/s Supports up to 128 preset positions, cruise, and auto patrol modes
AI Detection Features	Intrusion detection, boundary crossing, object left-behind, loitering, vehicle and personnel behavior analysis
Event Management	Real-time event-triggered alarms (audio/visual alerts, push notifications, or central control linkage)
Streaming Capability	Dual or triple stream output; main stream supports up to 4K@30fps
Communication Protocols	RTSP / ONVIF / HTTP / HTTPS / API integration
Protection Rating	IP66 waterproof and dustproof; optional IK10 impact resistance
Operating Temperature	-30°C to +60°C (industrial version up to -40°C to +70°C)
Power Supply	DC12V / PoE+ (802.3at) / AC24V
Power Consumption	≤25W (≤40W with IR and full PTZ functions enabled)
Installation Methods	Wall, pole, or ceiling mount; multi-angle adjustment supported
Housing Material	Aluminum alloy casing with anti-corrosion coating, suitable for outdoor environments

Core Functions

360° Panoramic Monitoring + PTZ Control

Provides all-around surveillance with remote pan, tilt, and zoom control for event-focused monitoring.

Zoom Capability

Combines optical and digital zoom for rapid magnification and detailed recognition of objects and scenes.

Low-Light & Night Vision Modes

Equipped with infrared LEDs or full-color low-light functionality to enhance visibility in dark environments.

Intelligent Event Detection

Detects human and vehicle entry/exit, boundary crossing, loitering, or unattended objects, supported by video analytics and AI models.

Cloud / Local Recording & Playback

Supports pre- and post-event recording, timeline playback, and event tagging for efficient evidence review.

Multi-Stream & Multi-User Access

Delivers video streams in various resolutions and frame rates for both front-end viewing and back-end storage or tracking.

Alarm & Notification System

Automatically sends alerts via push notifications, email, or system messages when anomalies are detected.

System Integration & Remote Monitoring

Offers APIs and standard interfaces for seamless integration with surveillance platforms, IoT/AIoT security systems, or city-level monitoring backends.

Application Fields

Parking Lots & Garages

Large-area monitoring for vehicle entry, license plate recognition, and illegal parking prevention.

Transportation Hubs (Stations, Airports, Ports)

Public safety monitoring, real-time incident detection, and crowd tracking.

Shopping Malls / Public Squares

Crowd flow analysis and abnormal behavior detection (loitering, lingering, crowding).

Industrial Parks & Warehouses

Comprehensive factory surveillance with detailed playback for critical zones.

Smart City Public Safety

Street monitoring, nighttime patrols, and public facility security.

High-Risk or Crime-Prone Areas

Rapid identification of suspicious activity, intrusion, and property loss events.
